Hot Sale Metal Laser Cutting Machine Laser Cut Industrial Machinery Equipment 6090 1390 6040

Share to:

Hot Sale Metal Laser Cutting Machine Laser Cut Industrial Machinery Equipment 6090 1390 6040

5 0 Reviews

1. Aluminum knife or honeycomb table. Two kinds of tables are available for different materials.
2. CO2 Glass sealed laser tube China famous brand (EFR, RECI), good beam mode stability, long service time.
3. Imported lens and mirrors. High transmittance, good focusing, reflection effect.
4. Ruida Controller system, support online/offline working, English language system, adjustable cutting speed and power. 5 High accuracy stepper motors and drivers. Belt transmission.
6. Taiwan Hiwin Linear square guide rails, higher precision.

model:	RF-6040 RF-1390 RF-9060
Availability:

Quantity:


Inquire Add to Basket

Model: RF-6040 RF-1390 RF-9060
Brand: RayFine

1390

Linear guide

100% real PMI / HIWIN linear guide has high precision and long life

IMGP7272

Ruida controller

Control the machine operation Z key control panel lift more convenient

IMGP7266

Laser head

High precision CO2 laser head, Suitable for high precision engraving

1647997992(1)

Forma wheel

Can be fixed,higher load bearing capacity,mute wheels

IMGP7278

Laser tube

RECI Laser tube,lifetime more than 10000hours,18 months warranty,fine laser beam quality

IMGP7258

Industrial chiller

It is recommended to choose CW3000 for laser tubes below 80W (W1), and CW5000 or CW5200 for laser tubes above 80W

photobank (1)

Focus lens

Cutting and engraving, can choose 63.5 focus lens, if mainly engraving and the material thickness is small, can choose a 50.8 focus lens

photobank (2)

Table

Aluminum knife table: suitable for hard materials such as acrylic, MDF, plywood, wood, etc
Honey comb table: suitable for soft materials, such as paper, cloth, leather, etc

photobank

Sample Show

Applicable Industries:Model industry (construction models, aviation and navigation models and wooden toys), advertisement, decoration, arts and crafts, electronic and electric appliances, garment industry fabric leather cut, etc.

Working materials: Nonmetal materials such as acrylic, MDF, wood planks (light planks, paulownia wood), bamboo ware, double-color sheets, paper, leather, shells, coconut shells, ox horns, resin, animal grease, ABS boards, lampshade, etc.

photobank (3)

Workshop pictures

gongchang1

*Verify Code

Related Products

RF-9060 Professional CO2 Laser Cutting Machine 80w 100w 130w 150w

Fiber Laser Marking Machine 50w China Factory Fiber Laser

3D 5W 10W 15W UV laser marking machine for engraving drinking glass wine glass curved surface

High Quality Welding Machine Handheld Laser Welding Machine for Metal

MACHINE PARAMETER
Product name	Laser cutting machine
Type	CO2 laser
Model	1390/9060/6040/1310/1610
Laser source	RECI Laser source
Marking area	1300X900MM/900X600MM/600X400MM
Control System	Ruida
Operating software	RDWORKS
X Y motor	Leadshine three-phase motor/Leadshine hybrid servo/ordinary three-phase motor
System environment	Windows 7 / 8 / 10
Water colling method	Water colling , Chiller CW3000/CW5000/CW5200
Guide	PMI/HIWIN Or Ordinary Linear Guides
Lifting platform control	Motorized up and down （57 two-phase motor）
Focus lens	D20 63.5/50.8 ordinary lens / II-VI lens
Graphic format supported	AI, BMP, DST, DWG, DXF, DXP, LAS, PLT, etc
Power supply	AC220/110V±10% 50/60hz
Warranty	2 year

MACHINE PARAMETER
Product name	Laser cutting machine
Type	CO2 laser
Model	1390/9060/6040/1310/1610
Laser source	RECI Laser source
Marking area	1300X900MM/900X600MM/600X400MM
Control System	Ruida
Operating software	RDWORKS
X Y motor	Leadshine three-phase motor/Leadshine hybrid servo/ordinary three-phase motor
System environment	Windows 7 / 8 / 10
Water colling method	Water colling , Chiller CW3000/CW5000/CW5200
Guide	PMI/HIWIN Or Ordinary Linear Guides
Lifting platform control	Motorized up and down （57 two-phase motor）
Focus lens	D20 63.5/50.8 ordinary lens / II-VI lens
Graphic format supported	AI, BMP, DST, DWG, DXF, DXP, LAS, PLT, etc
Power supply	AC220/110V±10% 50/60hz
Warranty	2 year
