RAYCUS JPT MOPA 30W 50W 60W 80W 100W 120W Laser Marking Machine Fiber Laser Engraver for Plastic/Metal/Gold/Silver/Copper/Stainless Steel/Alloy/Aluminum

5 0 Reviews
1. Split portable type design easy for shipping that DHL or FedEx or TNT.
2. High quality alumina shell, strong and beautiful. The net weight of the machine is about 45~55KG.
3. Motorized z axis, switch control z axis up and down.
4. Galvo head with double red dots, easy to find focus length.
5. Genuine BJJCZ control card and EZCAD software
Color:
Availability:
Quantity:
  • 20W 30W 50W 60W 80W 100W 120W

  • ray fine tech

  • 845611

MACHINE PHOTOS

20W 30W 50W 60W 80W 100W 120W laser marking machine

Fiber laser is widely used in marking metal and non-metallic plastics and other materials. High power that 50W 60W 80W 100W is more suitable for deep engraving and cutting 1mm thickness of small jewelry gold, silver and copper

DSC04204


DSC04210


PRODUCT DESCRIPTION

Motorized UP and DOWN

We installed a stepper motor on the machine's column, so we use a switch to control the machine UP / DOWN, which is convenient and fast

ADSC04212

X3


500mm height of motorized  z aixs column with clear ruler

x7


Digital Galvanometer (Galvo head)

*Double red dots easy to focus , they help you find the focal length

*Precise: Long time drift (work continuously for 8 hours) <0.3m Rad

20211004_160652


JPT laser source (Fiber series and MOPA series)

*Fiber laser series is 20W 30W 50W , 1~600khz laser frequency, 200ns laser pulse width; MOPA series is 20W 30W 60W 80W 100W 120W, 1~4000khz laser frequency, 1~500ns laser pulse width.  MOPA series is better, has stronger energy, and has a larger adjustment range.

*Stable working performance and a service life of more than 80,000 hours.

*JPT laser source come with smart cooling fan the fan only working when laser source over certain temparature, low noise.

800


Genuine control system BJJCZ and free EZCAD software(you can install the EZCAD software on Windows7,Windows8,Windows10)

H4ffd732232c64ae0bd4e665be036cd9cB

EZCAD software

333333333-1


LASER MARKING MACHINE DATASHEET


Machine name laser marking machine
Laser power 20W ~ 120W optional
Laser type and brand

fiber laser (JPT/RAYCUS/MAX)

Laser frequency

JPT fiber laser 1~600khz

JPT mopa laser 1~4000khz

Laser wavelength

1064nm



Marking area (optional)

70X70mm

110x110mm

150x150mm

175x175mm

200x200mm

220x220mm

250x250mm

300x300mm

Marking depth <1.5mm depend on engraving time
Marking speed 7000mm/s
Minimum marking character 0.1mm visible
Control software EZCAD 2
Control software support Vector graphics / Bitmap / DXF and other file formats
Control software operation Windows 7 / 8 / 10
Machine work voltage AC110V 60HZ, AC220V 50HZ  ±10%
Machine power consumption <700W
Machine cooling way Air cooling


PACKAGING & SHIPPING

*Packing box: plywood case, 790x410x750mm

*Clean and sanitize the machine

*Wrap the waterproof membrane

*Fill with foam

*Add  fixed rope

稿定设计导出-20211118-114232

IMG_20220111_163812

运输方式

OUR SERVICES

-We provide free YouTube operation videos and PDF English manuals.

-We have professional after-sales technicians who can assist through WeChat, Email, WhatsApp, Teamviewer.

-Before packing  in our factory, we do a 24-hour test. When you receive the machine, connect to the computer and you can use the laser directly.

-We Provide Free Ezcad Software.

COMPANY INFORMATION

We produce laser marking machine, laser Engraving Machine, laser cutting machine, laser welding machine, a variety of laser equipment. Types include fiber laser, CO2 laser, UV laser, 3D laser, MOPa laser. We look forward to working with you.

IMGP4888888


H9c010883fe18489eb58ee8e5f092a2d1C


gongchang1

OPTIONAL PARTS


We also sell a variety of optional parts and spare parts, welcome your inquiry.

82


83




Sample show

3x3

31

32



1配件
