300W laser cut 1390 1310 metal and no metal laser cutting machine for cutting steel wood plywood acrylic

5 0 Reviews
Availability:
Quantity:
Inquire Add to Basket

  • RF-1390 RF-1310

  • RAY FINE

  • 845611

300W laser cut 1390 1310 metal and no metal laser cutting machine for cutting steel wood plywood acrylicDSC01280

003


Technical parameter

Applicable materials: wood,MDF,acrylic,plastic,plexiglass,crystal,rubber,fabric,paper, stainless steel etc.
Model
YJ-CO2-1310
Focus lens
USA imported D20mm/FCL63.5mm
Power supply
AC220/110V±10% 50/60hz
Working area
1300*1000mm
Laser heads quantity
1
Laser power
180-300W(optional)
Max moving speed
500mm/s
Laser energy control
by LCD panel or software
Working table
Up&down Aluminum knife +Honeycomb table
Locating precision
<0.01mm
Min shaping character
letter 0.5mm, Chinese 0.5mm
Operating temperature
-5℃-35℃
Resolution ratio
4500dpi
Control program
RDWORKS
Data transfer interface
USB
System environment
Win7/8/10
Cooling way
Chiller CW5200 with protection system
Graphic format supported
The file which CorelDraw, Photo shop, Auto-CAD can identify
Compatible software
CorelDraw, Auto-CAD etc.
Cutting thickness
0-25 mm (depends on different materials)
Color separation
Separation of cutting up to 256 colors
Red dot pointer
yes
Open door safety
yes
Packing
Plywood
Net weight
350kgs
gross weight
450kgs

Machine details




三个大尺寸亚克力窗口

Hiwin PMI Liner railfor big work piece pass through

door protective sensor

monitor of amp and voltage

controller


20220729_142827

jpg

Inquiry to sales05@rayfinetech.com, thank you :)
